120cm Muck Grab Grapple Euro Hitch 750kg Capacity
Estimate only. Final freight options are confirmed in checkout.
FIHMGL120
Much Grab Grapple 120CM 750KG with Euro Hitch suit Tractor FEL and Skid Steer Loader
The Millers Falls FIMG120 Muck Grab is a durable and reliable attachment for your tractor loader or skid steer loader. It comes in a width of 1200mm the perfect size for your needs. The construction of the muck grab is made of 355 carbon steel, as per Millers Falls' high specifications, ensuring a long lifespan for the implement.
The muck grab comes with hydraulic hoses and couplers, making it easy to connect and use with your equipment. The low back of this muck grabs at 750mm provides better visibility over the implement, allowing you to see what you are doing. This feature is especially useful when working with objects such as trees, logs, hay bales, feed bags, and mulch, as the muck grab is designed to quickly and easily pick up and move these items.
The hydraulic system provides strong gripping force, making it much easier to handle heavy loads compared to manual grapple units. The simple construction and operation of the muck grab ensures reliable and efficient performance, making it one of the best accessories you can own. Whether you are a farmer or a tree lopper, this unit will become an indispensable tool in your work.
The grapple can open to a wide angle of 88 degrees and has a gripping capacity of up to 0.4m3. However, it is important to note the maximum capabilities of your loader and avoid overloading, as the muck grab itself weighs 150kg.
This heavy-duty implement is perfect for various manure moving jobs on and around the farm. It features a hydraulic ram operating across the top of the machine and is equipped with heavy-duty straight tynes at the bottom and curved tynes at the grab. The construction includes tapered tine sockets to ensure secure and tight tyne placement even after rigorous use.
Muck grabs are versatile and crucial pieces of equipment in agricultural work, they are specifically designed for grabbing and moving muck, including silage and manure, providing a secure and efficient way to transport these materials. The heavy-duty construction ensures durability and reliability, allowing the attachment to withstand daily use for a long period of time.
Features:
All brackets on generous 8mm thickness support plates with generous margins to spread stress.
Underside scuff plates
Grease points for long life
Designed to fit Euro hitch front end loaders and skid steers
Includes hoses and male flat-face couplers
Oversized hydraulic ram
Heavy-duty steel frame construction
Powder coated finish
Euro Hitch measurements
Top hook diameter 40mm
Lower pin hole diameter 23mm
319mm from top of top hook to centre of lower pin
740mm inside to inside of lower pins
1080mm outside to outside of top hooks
Specifications:
Model: FIHMGL120
Max Payload: 750kg (Subject to Tractor or Skid Steer Capacity)
Overall Height: 750mm
Overall Width: 1220mm
Overall Depth: 600mm
Number of Bottom Tynes: 7
Number of Grab Tynes: 4
Max Opening Height: 1135mm
Connection Type: Euro Linkage
Packing dimensions: 1220 x 750 x 63cm
Weight: 150Kg
