16HP Vertical Shaft Petrol Engine 452cc Electric Start

QPVS16ES

Millers Falls TWM 16HP Vertical Shaft Engine Lawn Mower Petrol Motor 4 Stroke

The 16HP Push Mower Engine Electric Start is an excellent replacement motor for lawn mowers but can also be used for other applications. You will enjoy the lightweight and dependable QPVS16ES push mower engine. Providing a combination of reliable power and exceptional value, this is an excellent quality engine with electric start at an exceptional price. It features a vertical shaft and is suitable for a number of different applications.

Features:

Optimized balance system, vibration reduction and more stable operation.

Overhead valve (OHV) design and lower engine temperature

Secondary oil filtration system enables better lubrication of engine, reduces wear and prolongs engine life

Cast iron casing does not only effectively improve lubrication, but also makes engine more resistant to wear and prolongs engine life

Metal cam and forged crankshaft makes engine more reliable and durable.

Type 16HP vertical shaft engine

Engine Type 16HP 4 stroke air cooled OHV

Combustion System Spark Ignition

Cylinder 1 – cast iron

Shaft diameter 1”

Shaft Length: 80mm

Displacement 452cc

Specifications:

Bore & Stroke 92 x 68mm (Bore/Stroke Ratio: 1.353)

Operating Speed Range 2800~3200rpm

Maximum Torque 2600r/min

Compression Ratio 8.8

Fuel Type: Petrol

Cooling System Forced air

Overall Size (not including shaft) 415 x 442 x 315mm

System Voltage  12V

Shipping Dimensions 72 x 55 x 56 (cm) x 45kg
