CPC85BS
Plate Compactor 82k 5.0 HP with Briggs & Stratton 1062 Engine
Description:
The CPC85BS 82kg plate compactor is a versatile and powerful machine designed to provide efficient compaction of various materials.
With a ductile cast-iron heavy-duty base plate this unit is suitable for most types of compaction work,
hot and cold asphalt work even brick paving compaction (using rubber mat, not supplied).
Features:
Fully enclosed V-Belt drive for better safety and trouble-free use.
Square shaped bed and handles enabling changing direction with ease.
Curved edges for easy access into corners during compaction.
Foldable handle easy for transportation and storage
Built-in fold away wheels for easy transportation
Built in lifting hook allowing loading and unloading with lifting device.
Open bottom plate to facilitate self-cleaning.
Heavy-duty shock mounts reduce vibration to the upper engine & handle.
Heavy duty industrial throttle control is available as standard
Specifications:
Engine Type : Air-Cooled Single Cylinder 4-Stroke
Engine : Briggs & Stratton 1062
Power (HP) : 5.0
Size of Base Plate (L x W) (cm) : 59.5 x 42
Max. Centrifugal Force (KN) : 15
Vibration Frequency (V·P·M) : 5000
Compaction Depth (cm) : 30
Travel Speed (cm/s) : 25
Net weight (Kg) : 82
Shipping weight (Kg) : 88
Shipping Size (L x W x H)(cm) : 80 x 51.5 x 67
