SKU: ATXACB3050-A
In stock
$631.00
Shipping calculated at checkout
ACB3050A

Air Compressor Belt Drive 2 Cylinder Alloy Pump 3 HP 50 Litre Receiver 240 Volt

Description:

The Millers Falls Belt Drive 3 HP 250 LPM with 50 Litre tank air compressor is a reliable and powerful tool that is ideal for use with air tools requiring a constant supply of compressed air. It has a displacement of 250 litres per minute (9 CFM) and a delivery rate of 230L/min, making it suitable for a variety of workshop and building site air tools.

The compressor is constructed with high-grade materials and superior craftsmanship, ensuring durability and reliability. It comes pre-filled with oil, air filters, and pulley for optimal performance. The Twin Cylinder Alloy Pump is known for its long-lasting and cost-effective performance as well as being quieter and cooler running compared to cast iron pumps.

This Heavy-Duty Italian Style Air Compressor is perfect for all air tools and workshop use. With its 3.0 horsepower electric motor and belt driven twin piston alloy pump the 50L air receiver is repressurised quickly and efficiently. It features easy-to-read dual pressure gauges and twin Nitto style quick connect regulated outlets, making it great for most air tools. The bottom drain valve allows for easy removal of condensation from the tank after use. The large ergonomic handle and two large industrial wheels with integrated bearings make it portable and easy to transport.

The alloy side by side compressor pump has a cast iron bore giving the pump longevity and together with the alloy body allows for efficient heat transfer and low noise generation. The reed valves are made of high-quality stainless steel for durability. The oversized flywheel provides greater airflow over the pump, cooling the entire piston barrel. Being a twin cylinder inline pump, it has a balanced stroke which reduces vibration, noise, amps, and wear on the motor.

The availability of spare parts provides peace of mind when investing in this equipment.

The dual gauges clearly show the amount of air in reserve and the delivered pressure, allowing for easy adjustment to suit specific work requirements. The belt-drive layout of this compressor makes maintenance straightforward and helps reduce noise compared to direct-drive units. The vibration-absorbing foot underneath the tank prevents mechanical shocks and further reduces noise. The compressor is mounted on two heavy-duty wheels and has a handle for easy transportation in a workshop or work site.

The Millers Falls Belt Drive 3 HP 9 CFM 50 Litre tank unit air compressor is a powerful and reliable tool suitable for workshops and serious DIY projects. Its high-power output, large tank capacity, and durable construction make it a great option for professionals.

Features:

  • Two Cylinder Alloy Pump with Cast Iron Liners

  • Copper Winding Electric Motor

  • Durable - High quality components & fittings.

  • Includes: 2 Gauges and 2 Nitto style connectors

  • Air Filter and Pressure Regulator

  • Rear Tank Outlet with Pressure Gauge & Nitto Fitting

  • Full Style Belt Cover

  • 10-amp SAA approved Plug

  • U Shaped Handle

  • 2 Regular Black Wheels & 1 Universal wheel

Specifications:

Model: ACB3050A

Displacement: 250L/min Max (9cfm)

Power: 2250W (3.0HP/2.2kW)

Tank: 50ltr – Dual Tank Plugs

Air Flow @ 8 Bar: 230L/min

Air Flow @ 4 Bar: 280L/min

Noise: 73dB

Pump: 2 x 65mm Cylinders

Includes: Gauge and 2 Nitto style connectors

Full Style: Belt Cover

10-amp SAA approved Plug

U Shaped Handle

2 Regular Black Wheels & 1 Universal wheel

Package Size: 95x40x71cm

Weight: G.W = 64kg   N.W = 56kg
