Grooving Machine - Cpgm180Hc

SKU: ATXCPGM180HC
Out of stock
$10,000.00
Shipping calculated at checkout
CPGM180HC

Grooving Machine

Features:

The Millers Falls CPGM180HC Concrete Groover is a compact and maneuverable machine that can be used for a multitude of grooving and grinding applications. This unit is perfect for concrete grooving, grinding or roughing for repair work or anti slip applications.

Great for grooving and grinding projects where large machines cannot access. Ideal for enlarging cracks in footpaths, roads or concrete areas to enable a more permanent repair job.

Reliability:

Heavy duty construction to handle small or big jobs. The unit is supplied with a powerful Millers Falls 13HP engine fitted with a triple belt drive to the heavy-duty cutting head providing maximum torque and trouble-free use. High speed performance is all but guaranteed.

Safety:

Useful for creating textured anti-slip areas for improved traction on slippery concrete surfaces. Safety switch fitted as standard. Fully enclosed V-belt for greater safety and trouble-free use.

Easy Operation:

Groove depth can be easily adjusted using the robust winder handle. Vibration absorbing handles for ease of use and reduced operator fatigue.

MODEL
CPGM180HC

Engine

Millers Falls 390F

Engine Power (HP)

13 Manual Start

Blade Diameter

180 mm x 20mm Bore

Blade Thickness

8 mm

Blade Quantity

1 (can be used with 2 blades)

Shaft Speed

3000r/min

Groove Depth

0-40mm

Groove width single blade

8-10mm

Groove width twin blade

16-20mm

Cutting speed

2-4m/min

Operating Model

98 x 63 x 91cm

Net weight

81 Kgs

Shipping weight

91 Kgs

Package size

98 x 63 x 91cm
