SKU: ATXLHTJM8050
In stock
$2,621.00
Shipping calculated at checkout
LHTJM8050

MULTI STAGE TRUCK JACK 80/50T

Description:

The LHTJM8050 - MULTI STAGE TRUCK JACK 80/50T is a robust air hydraulic jack engineered to deliver exceptional lifting capacity for the most demanding heavy-duty applications. Featuring a safe working capacity of 80,000 kg (80T) in the first stage and 50,000 kg (50T) in the second stage, this multi-stage jack is perfect for lifting large trucks, industrial machinery, buses, and other heavy vehicles in a variety of professional and industrial environments.

This multi-stage jack is designed for high performance and efficient lifting. With a hydraulic lift of 111 mm in the first stage and 102 mm in the second stage, the LHTJM8050 ensures smooth, controlled lifting across a wide range of vehicles. The minimum height of 230 mm and maximum height of 565 mm provide a flexible lifting range, while the 75 mm and 45 mm adaptors enhance versatility.

A key feature of the LHTJM8050 is its quiet operation. Unlike traditional truck jacks, which can be noisy during use, the LHTJM8050 has been specially designed to operate much more quietly, reducing noise levels in busy work environments. This makes it an ideal choice for workshops or repair facilities where noise reduction is important for operator comfort and safety.

The LHTJM8050 operates efficiently within an air pressure range of 0.9-1.2 MPa (145-175 psi), ensuring quick and reliable lifts with minimal manual effort. The jack is easy to maneuver, with a 1380 mm handle length for better control. Despite its powerful lifting capabilities, it is still relatively portable, weighing 106 kg and featuring a compact package size of 980 x 390 x 230 mm.

The LHTJM8050 - MULTI STAGE TRUCK JACK 80/50T is a high-capacity, efficient, and quiet jack that excels in heavy-duty lifting tasks. Whether you are lifting large trucks, buses, or industrial equipment, this jack delivers exceptional power while reducing operational noise. Its versatility, robust construction, and quieter performance make it a standout choice for industrial environments and workshops that require powerful lifting with less noise disruption.

Key Features:

  • First Stage Capacity: Lifts up to 80,000 kg (80T), ideal for heavy trucks, buses, and industrial machinery.

  • Second Stage Capacity: Lifts up to 50,000 kg (50T), providing flexibility for a variety of lifting needs.

  • Hydraulic Lifts: 111 mm lift in the first stage and 102 mm lift in the second stage for smooth, controlled operation.

  • Lifting Range: Min height: 230 mm, Max height: 565 mm, offering flexibility for vehicles with different ground clearances.

  • Adaptors Included: Comes with 75 mm and 45 mm adaptors for added versatility in lifting.

  • Operating Air Pressure: 0.9-1.2 MPa (145-175 psi), ensuring optimal lifting power with minimal manual effort.

  • Silent Operation: Designed to operate more quietly than conventional truck jacks, reducing noise levels in busy work environments.

  • Durable Construction: Built for long-lasting performance and reliability in heavy-duty conditions.

  • Portable & Easy to Use: Weighs 106 kg, with gross weight of 115 kg, and packing dimensions of 980 x 390 x 230 mm, making it easy to transport and store.

  • Handle Length: Features a 1380 mm handle for easy maneuvering during operation.

Specifications:

Model: LHTJM8050

First Stage Capacity: 80,000 kg (80T)

Second Stage Capacity: 50,000 kg (50T)

First Stage Hydraulic Lift: 111 mm

Second Stage Hydraulic Lift: 102 mm

Minimum Height: 230 mm

Maximum Height: 565 mm

Adaptors: 75 mm and 45 mm

Handle Length: 1380 mm

Operating Air Pressure: 0.9-1.2 MPa (145-175 psi)

Chassis Dimensions: 930 x 340 x 230 mm

Nett Weight: 106 kg

Gross Weight: 115 kg

Packing Size: 980 x 390 x 230 mm

Handle Box Dimensions: 1390 x 280 x 110 mm

Shipping cost is calculated at checkout.
