RAZOR 175 MIG/STICK Welder

UMGKUMJRRW175MIG

Vendor: UNIMIG

$817.00
$1,075.00 $817.00
Sale Sold out
Tax included. Shipping calculated at checkout.

Shipping is calculated at checkout.
View full details

The RAZOR™ 175 is the perfect MIG and STICK welder for the professional welder wanting a powerful machine with a portable body. Fitted with a 15 AMP plug, this machine is designed for the workshop and for site work. The Spool Gun connection gives you the added flexibility of using softer wires and smaller spools, giving you all the features you need in a lightweight machine.



GAS & GASLESS MIG

This machine supports both gas shielded MIG and gasless MIG wire, meaning you can easily run mild steel, aluminium, flux-cored, silicon bronze and stainless steel MIG wire.



SPOOL GUN READY

This machine is Spool Gun ready, so you have the option of attaching a Spool Gun to run softer core wires such as Aluminium MIG wire. The advantage of the Spool Gun is that you do not need to change the setup of your existing torch or drive roller. The spool gun lets you quickly switch over to get the job done with no downtime.





Product No: KUMJRRW175MIG

MACHINE SPECIFICATIONS

PRIMARY INPUT VOLTAGE

240V Single Phase

SUPPLY PLUG

15 AMP

RATED INPUT POWER (kVA)

6.7

Ieff (A)

14.8

RATED OUTPUT

30A/15.5V - 175A/22.8V

NO LOAD VOLTAGE (V)

53

PROTECTION CLASS

IP21S

INSULATION CLASS

F

POWER FACTOR

0.7

MINIMUM GENERATOR (kVA)

11.0

DINSE CONNECTOR

35/50

STANDARD

AS/NZ60974-1

SUITABLE MATERIAL

Mild Steel, Stainless Steel, Cast Iron, Silicon Bronze, Aluminium

WARRANTY (Years)

3

MIG SPECIFICATIONS

MIG WELDING CURRENT RANGE

30-175A

MIG DUTY CYCLE @ 40°C

25% @ 175A

MIG WIRE SIZE RANGE

0.6-0.9mm


MIG WIRE SPOOL SIZE

1kg / 5kg

MIG WELDING THICKNESS RANGE

1-8mm

DRIVE ROLLER SIZE

30/10

STICK SPECIFICATIONS

STICK WELDING CURRENT RANGE

10-160A

STICK DUTY CYCLE @ 40°C

25% @ 160A

STICK ELECTRODE RANGE

2.5-4.0mm

STICK WELDING THICKNESS RANGE

2-10mm



SIZE & WEIGHT

DIMENSIONS (mm)

470x190x380mm

WEIGHT (kg)

12.5kg



MACHINE FEATURES

WIRE DRIVE

Standard

VRD

Yes

SPOOL GUN CONNECTION

Yes

BURNBACK ADJUSTMENT

Yes

WIRE INCH

Yes

THERMAL OVERLOAD PROTECTION

Over Temperature Warning
